Automatic High Speed Self Adhesive (Sticker) Labelling Machines. Models: AHL-150SA and AHL-300SA
Automatic High Speed Self Adhesive (Sticker) Labelling Machines. Models: AHL-150SA and AHL-300SA
These are linear motion sticker labeling machine use for radial or partial warp or overlap labelling on vials.
It is equipped with container separator system to synchronise the container speed with label length. It gives good labelling accuracy and can handle different size of vials without any change parts.
Product Details
Technical Specifications
AHL-150SA
Output/Hour
6,000 – 7,200 Vials (Depends upon Container size & label size)
Vial Sizes
2 ml to 100 ml
Label Sizes
Length - 20 mm to 200 mm
Width - 10 mm to 80 mm
Machine Dimensions
2500 mm (L) X 900 mm (W) X 1800 mm (H) (Approx.)
AHL-300SA
Output/Hour
12,000 – 14,400 vials (Depends upon Container size & label size)
Vial Sizes
2 ml to 100 ml
Label Sizes
Length - 20 mm to 200 mm
Width - 10 mm to 80 mm
Machine Dimensions
2500 mm (L) X 900 mm (W) X 1800 mm (H) (Approx.)
Salient Features
- Suitable for Radial/ Partial/Overlap Labeling
- “No Container – No Label” sensing device avoids wastage of labels
- Advanced stepper drive for label dispensing unit
- A/C frequency drive for speed control
- An inbuilt digital counter provides continuous information of labeled containers
- An inbuilt real – time speed indicator will show actual speed of machine
- An inbuilt PLC and HMI for control and operation of machine
- No need of any change parts during changeover of size
Optional Accessories
- Inkjet printer to print batch details on labels
- Toughened glass safety cabinet
- Advance camera to inspect the printed batch details
- Computer system with SS stand to teach camera the parameters to inspect on labels
- Rejection mechanism to reject the vials in case of no label on vial, no printing on label and faulty printing on label
- FDA 21 CFR Part 11 compliance with high end industrial touch screen and PC
