Automatic High Speed Wet Glue Combo Labelling Machine for Round Containers. Model: AHL-150 Combo
Automatic High Speed Wet Glue Combo Labelling Machine for Round Containers. Model: AHL-150 Combo
Automatic High Speed Wet Glue Round Bottle Combo Labelling Machine is suitable for achieving high speed labelling with a combination of two machines juxtaposed – 1st in right to left direction and 2nd in left to right direction.
is suitable for radial or partial warp or overlap labelling on round PET, HDPE or glass bottles or any other round container used in pharmaceuticals, food and beverages, cosmetics or in any other industries.
This is a purely mechanical robust machine which has sturdy design ensuring minimum vibrations and thereby delivering better labelling accuracy. It is very operator friendly machine and also takes minimum changeover time for change parts.
Product Details
Technical Specifications
12,000 - 14,400 Bottles
5 ml to 200 ml
Length - 20 mm to 140 mm
Width - 10 mm to 90 mm
3200 mm (L) x 1750 mm (W) x 1100 mm (H) (Approx.)
Salient Features
- Special design to achieve high speed wet glue labeling on round containers
- Suitable for overlap labelling & flag type labelling
- Totally SS finished (cGMP)
- Inbuilt vacuum pump
- Inbuilt A.C drive for speed control
- Inbuilt In feed 30ӯ turntable
- “No Container – No Label” – a pneumatic – sensing device avoids wastage of labels
- Special self – aligning bearings ensure smooth and Lifetime trouble free rotation of the parts
- An in – built mechanical counter provides continuous information of labelled containers
- Minimum change – over time required from one size to another
Optional Accessories
- Code over printing device
- Safety guard
